Downloads

• HT ITALIA VEGA 78/DATASHEET.PDF
• HT ITALIA VEGA 78/HT ITALIA%20VEGA78 USER MANUAL.PDF

Features

• TRMS P-N, P-P, P-PE voltage measurement (5 inputs)
• TRMS current on phases and neutral (4inputs)
• Active, reactive and apparent power measurement
• Active, reactive and apparent energy measurement
• Power factor measurement
• Frequency measurement
• Up to 251 selected parameters at the same time
• Integrated period selectable from 1s to 60min
• Harmonic analysis of voltage and current up to 49th harmonic
• Voltage anomalies (sags, swells) with 10ms resolution
• Numerical and graphical (waveforms) visualisation
• Histogram visualisation of harmonic analysis
• Vector diagram of voltages and currents
• Voltage unbalanced
• Predefined recordings of parameters
• TFT colour display with "touch screen"
• 15Mbytes internal memory for record storage
• External compact flash and USB pen drives USB interface for PC connection
• Windows software for analysis
• Rechargeable Li-Ion battery and external AC/DC adapter
• Contextual help selectable on each screen
• Virtual keyboard display
